Order code |
||||
|
2WK |
160 |
– |
10 |
AC110V |
|
2/2 way Solenoid valve |
Orifice size 160: 200: 250: 350: 400: 500: |
Port size 10:3/ 15:1/2" 25:1" 35:11/4" 40:112" 50:2" |
Voltage DC12V DC24V AC24V 50/60Hz AC110V 50/60Hz AC220V 50/60Hz AC380V 50/60Hz |
|
|
Specification |
||||||||
|
Model |
2WK160-10 |
2WK160-15 |
2WK200-20 |
2WK250-25 |
2WK350-35 |
2WK400-40 |
2WK500-50 |
|
|
Fluid |
Air,Water.Gas.Oil (filtered through 40u filter element) |
|||||||
|
Action |
Direct acting type
|
|||||||
|
Type |
Normally closed type |
|||||||
|
Effective area(mm2) |
16 |
16 |
20 |
25 |
35 |
40 |
50 |
|
|
CV Value |
4.8 |
4.8 |
7.6 |
12 |
24 |
29 |
48 |
|
|
Prot size |
3/8" |
1/2" |
3/4" |
1" |
11/4" |
11/2" |
2" |
|
|
Viscosity limit |
Under 20CST |
|||||||
|
Operating pressure |
Water and oil: 0-5.0kgf/cm2 Air0-7.0kgf/cm2 |
|||||||
|
Proof pressure |
10kgf/cm2 |
|||||||
|
Ambient & fluid temperature |
-5~85oC |
|||||||
|
Voltage range |
±10 |
|||||||
|
Weight(kg) |
||||||||
|
Main parts material |
body |
Brass |
||||||
|
seal |
NBR |
|||||||
