Order code |
||||
|
3V1 |
– |
06 |
AC220V |
|
|
2/2 way Solenoid valve |
port size M5:M5" 06:1/8" |
Voltage DC12V DC24V AC24V 50/60Hz AC110V 50/60Hz AC220V 50/60Hz AC380V 50/60Hz |
||
|
Specification |
|||
|
Model |
3V1-M5 |
3V1-06 |
|
|
Fluid |
Air(filtered through 40u filter element) |
||
|
Type |
Direct acting type |
||
|
Action |
Normally closed type |
||
|
Effective area(mm2) |
2.5 |
||
|
CV Value |
0.23 |
||
|
Port size |
1/8" |
1/4" |
|
|
Viscosity limit |
Under 20CST |
||
|
Operating pressure |
0-0.7kgf/cm2 |
||
|
Proof pressure |
10kgf/cm2 |
||
|
Ambient & fluid temperature |
-5-85oc |
||
|
Voltage range |
±10 |
||
|
Weight(kg) |
|||
|
Main parts material |
Body |
Aluminum alloy |
|
|
Seal |
NBR |
||
