Order code |
|||||
|
Q |
23 |
X |
D |
2 |
B |
|
Series |
22:2/2way 23:2/3way |
Direct Acting type |
Electrically controlled |
Orifice size |
B :panel Connecting L: pipe connecting |
|
Specification |
|||
|
Model |
Q23XD |
Q22XD |
|
|
Pressure range |
0-0.8Mpa |
||
|
Proof pressure |
1.0Mpa |
||
|
Tum-around time |
≤0.04S |
||
|
Leakage quantity |
≤10cm2/min |
||
|
Life |
≥3 million cycles |
||
|
Voltage |
AC110V/AC220V/DC24V |
||
|
Weight(kg) |
|||
|
Main parts material |
Body |
Aluminum alloy |
|
|
Seal |
NBR |
||
