Order code |
||
|
AFR |
2000 |
M |
|
Filter regulator AFR: AC series BFR: BC series |
Port size 1500:1/8" 2000:1/4" 3000:3/8" 4000:1/2" |
Drain type Nil: semi-automatic drain M: manual drain A: auto drain |
|
Specification |
||||||
|
Model |
AFR1500 AFR AFR |
AFR2000 AFR AFR |
BFR2000 BFR BFR |
BFR3000 BFR |
BFR4000 BFR |
|
|
Port size RC(RT) |
1/8" |
1/4" |
1/4" |
3/8" |
1/2" |
|
|
Filud |
Air |
|||||
|
Adjustable pressure range |
0.5-8.5kgf/cm2 |
|||||
|
Max. pressure |
9.5kgf/cm2 |
|||||
|
Proof pressure |
15.0kgf/cm2 |
|||||
|
Ambient & fluid temperature |
5-60oC |
|||||
|
Nominal filtration rate |
40um |
|||||
|
Drain bowl capacity |
15CC |
60CC |
||||
|
Weight(kg) |
0.26 |
0.4 |
||||
|
Main parts Material |
Body |
Aluminum alloy |
||||
|
Bowl |
PC |
|||||
|
Bowl guard |
AFR 1500-AFR2000:without BFR2000-BFR4000:with（plastic） |
|||||
